Frames, shadows, buttons, plates 1 February 2008


Task:

Make a design element with an intricate frame and custom sizes using as few tags and files as possible.

In order to reduce the number of tags used you should prepare the right image. It’s an easy procedure—just take a look at framed.png. In the sample the width of button corners is 11 pixels and the height is 10 pixels. If want to alter the sizes, replace or span the previous values in your styles.

This approach doesn’t work in strict and transitional modes for IE 6 or lower.

How it looks in the browser

01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
<style type="text/css">

/* Styles for this sample */
.example
{
position: relative;
width: 100%;
padding: 20px;
background: url('../png_in_ie/grid-10.gif') 100% 100%;
overflow: hidden;
}
.horizontal
, .horizontal ul
{
list-style-type: none;
width: 100%;
margin: 0;
padding: 0;
}
.horizontal:after
, .horizontal ul:after
{
content: '';
display: block;
clear: left;
}
.horizontal li
{
float: left;
margin: 0 1em 0.5em 0;
padding: 0;
}
/*****************************/

/* Fixing IE cursor and hover behaviour */
.framed a
{
cursor: pointer;
//cursor: hand;
}
.framed a:hover
{
background-color: transparent;
}

/* Balancing IE negative margin-bottom value */
.framed.horizontal
{
//padding-bottom: 10px;
}

.framed .f
{
position: relative;
z-index: 1;
display: block;
float: left;
min-height: 10px;
//height: 10px;
color: #000000;
}
.framed .c
{
position: relative;
z-index: 2;
display: block;
margin: 0 0 -10px 0;
/* Padding around button; bottom padding 2 px meant for shadow */
padding: 2px 15px 4px 15px;
}
.framed .t
, .framed .b
{
position: absolute;
z-index: 1;
top: 0;
//top: auto;
bottom: 0;
left: 0;
right: 11px;
overflow: hidden;
//width: 100%;
//height: 100%;
}
.framed .b
{
top: auto;
bottom: -10px;
height: 10px;
}
.framed .r
{
left: auto;
//left: -11px;
right: 0;
//margin-left: 100%;
width: 11px;
}
.framed .t *
, .framed .b *
{
position: absolute;
top: 0;
left: 0;
/* Total image width and height; extra size possible */
width: 800px;
height: 400px;
background: url('framed.png') 0 0 no-repeat;
/* IE 7 is capable of viewing png, so hack it elsehow */
-background-image: none;
-filter: progid:DXImageTransform.Microsoft.AlphaImageLoader(src=framed.png,sizingMethod=crop);
}
.framed .t *
{
margin-top: -10px;
}
.framed .l *
{
//width: 100%;
margin-left: -11px;
}

/* Creating button hover effect */
.framed a:hover .t *
, .framed a:hover .b *
{
top: -200px;
}
</style>
<div class="example">
    <ul class="framed horizontal">
        <li>
            ../../etc/png-1/" class="f">
                <ins class="t l"><ins></ins></ins><ins class="t r"><ins></ins></ins>
                <ins class="c">About PNG. Part One</ins>
                <ins class="b l"><ins></ins></ins><ins class="b r"><ins></ins></ins>
            </a>
        </li>
        <li>
            ../../etc/png-2/" class="f">
                <ins class="t l"><ins></ins></ins><ins class="t r"><ins></ins></ins>
                <ins class="c">About PNG. Part Two</ins>
                <ins class="b l"><ins></ins></ins><ins class="b r"><ins></ins></ins>
            </a>
        </li>
    </ul>
</div>
